| parameter |
| Rated loading | 1200KG |
| Overall weight | 3450KG |
| Bucket capacity | 0.6m3 |
| Maximum traction force | 90Kn |
| Maximum breakout force | 48Kn |
| Maximum grade ability | 25℃ |
| Maximum turning radius (outside of the bucket) | 5600mm |
| Maximum turning radius (outside of the tire) | 4950mm |
| Overall dimension (L×W×H) | 5600*1810*2600mm |
| Engine |
| Model | Yunnei 36.8KW |
| Type | lnline water cooling dry cylinder injection |
| Rated power | 36.8kw-2400r/min |
| Maximum torque | 147N.M |
| Emission standards | China II |
| Transmission system |
| Torque converter | Single-stage four-element dual-turbine hydraulic torque converter |
| Gearbox mode | Planetary power transmission |
| Gears | 2forward shift 2reverse shift |
| Maximum speed | 25km/h |
| Drive axles |
| Main reducing spiral | Bevel gear grade 1reduction |
| Decelerating mode | Planetary reduction grade 1 |
|
| Wheel base (mm) | 2250mm |
| Wheel tread | 1600mm |
| Hydraulic system |
| System working pressure | 16MPa |
|
|
| Fight forward time | 6s |
| Fight time | 3s |
| Transmission system |
| Service brake | Four-wheel brake with oil cap and disc |
|
| Parking brake | Manual disc type |
| Tyre |
| Type specification | 20.5-70-16 |
|
| Front tyre pressure | 0.4Mpa |
| Rear tyre pressure | 0.35Mpa |
Construction wheel loader dump trucks are engineering machines that combine loading and unloading functions, commonly used in construction sites, mines, or agricultural settings to transport bulk materials such as sand, gravel, and earth. These machines typically use tires for locomotion and are equipped with a hydraulic tipping bucket, allowing for rapid material dumping via front or side unloading methods, improving construction efficiency. Main Features and Applications
Structure and Function: Mostly powered by diesel engines, equipped with four-wheel or three-wheel drive systems to adapt to complex terrain; bucket capacity generally ranges from 0.5 cubic meters to 1 cubic meter, supporting hydraulic lifting for easy loading and unloading.
Applicable Scenarios:
Widely used for short-distance transportation at construction sites, orchard transport, livestock manure removal, mining operations, etc., especially suitable for operation in confined spaces.
Common Types:
Includes small wheel dump trucks (such as 25-horsepower models), four-wheel drive loaders, telescopic boom forklifts, etc. Some models can be equipped with attachments such as log grapples and lifting platforms to achieve multi-functional operations. Price and Brand Reference
Price Range:
Prices vary significantly depending on load capacity, horsepower, and configuration. For example, basic small dump trucks are inexpensive, while larger equipment is customized to meet specific needs.
Representative Brand:
SEMGATY-009 is commonly seen in the construction equipment industry, emphasizing durability and ease of operation.
Selection Considerations
Site Adaptability:
The choice between wheeled or tracked models should be based on site road conditions. Wheeled models are better suited for paved surfaces, while four-wheel drive models can handle soft terrain.
Safety and Maintenance:
Prioritize models with hydraulic locking and anti-tipping designs, and regularly inspect the engine and tipping mechanism to ensure long-term stable operation.
For further information on specific model parameters or local supplier information, please refer to relevant equipment platforms or contact the manufacturer for detailed information.
