| parameter |
| Operating weight | 4.8t |
| Volume of Bucket | 0.12m³
|
| Engine model | Yangdong、Changchai、Yanmar |
| Power | 36.8Kw |
| Fuel trank | 80L |
| Travel speed | 16km/h |
| Swing speed | 11.5r/min |
| Bucket digging force | 24.2Kn |
| Hydraulic pump model | Load-sensitive pump |
| Maximum flow | 95L/min |
| Pressure | 20Mpa |
| Hydraulic oil tank | 60L |
| Overall length | 5453mm |
| Overall width | 1530mm |
| Machine height(Boom head) | 2091mm |
| Total height(tooperators cab top) | 2633mm |
| Ground clearance(bob- weight) | 813mm |
| Min.ground clearance | 208mm |
| Rear-end seing radium | 1538mm |
| Table width | 1530mm |
| Max.digging height | 5380mm |
| Max.dumping height | 3794mm |
| Max.digging depth | 3527mm |
| Max.vertical wall digging depth | 2201mm |
| Max.digging reach | 5856mm |
| The largest mining in stopping distance | 5704mm |
| Min.swing radius | 2146mm |
| Minimum turning radius at maximum height | 4183mm |
| Arm length | 1700mm |
| Boom length | 2800mm |
4.8-Ton Compact Excavator – Power, Precision, and Versatility
The 4.8-ton compact excavator is engineered to deliver exceptional performance in tight spaces and demanding work environments. Designed for urban construction, landscaping, utility projects, and medium-scale site preparation, this machine combines high digging power, agile mobility, and precise control, offering contractors a flexible and reliable solution.
Efficient Digging and Material Handling
Equipped with a reinforced boom and arm, this excavator provides a maximum digging depth of 3.5 m and a vertical wall digging capacity of 2.2 m, enabling operators to handle trenches, foundations, and drainage projects with ease. The bucket delivers a strong digging force of 24.2 kN, allowing the machine to tackle dense soil, clay, or compacted materials without sacrificing efficiency. Its telescopic arm and optimized geometry maximize reach while maintaining stability, ensuring accurate placement of excavated materials.
Reliable and Efficient Power
The excavator is powered by a robust diesel engine from YANGDONG, CHANGCHAI, or YANMAR, producing reliable torque and fuel efficiency for extended operating hours. Combined with a load-sensing hydraulic system, operators enjoy smooth boom, arm, and bucket movements, faster cycle times, and precise lifting under heavy loads. This efficiency translates to reduced fuel consumption and lower operating costs without compromising performance.
Exceptional Mobility and Stability
Thanks to its tracked undercarriage, the machine provides excellent traction across soft, uneven, or loose terrain, while the low ground pressure of 32 kPa minimizes surface damage. Its compact design and minimum turning radius of 1.4 m at the front end allow effortless maneuvering in confined job sites, urban streets, or landscaped areas. With travel speeds up to 4.5 km/h, operators can move quickly across the site, switching between excavation, grading, and light lifting tasks with minimal downtime.
Operator Comfort and Safety
The cab is thoughtfully designed for maximum visibility and ergonomic operation. Pilot-controlled joysticks enable intuitive control of all functions, giving operators full confidence when handling delicate or complex tasks. Ample headroom and well-positioned controls reduce fatigue during long shifts, while robust protective structures safeguard the operator in all conditions.
Durability and Ease of Maintenance
Built to endure the rigors of daily construction work, the boom, arm, and chassis feature reinforced steel construction for extended durability. Key hydraulic components are designed for longevity, and routine service points are easily accessible, reducing maintenance time and ensuring consistent productivity.
Versatile Applications
From residential projects and utility installation to landscaping and roadworks, this excavator offers unmatched adaptability. Its lifting capacity of up to 800 kg vertically and 520 kg horizontally allows light material handling tasks, making it a multi-functional machine for both digging and placement.
The 4.8-ton compact excavator blends strength, agility, and precision into a single package, giving operators the confidence to work efficiently in restricted spaces while maintaining productivity. Its combination of powerful hydraulics, fuel-efficient engine, and superior maneuverability makes it an ideal choice for contractors who demand versatility and reliability on every job.
