| parameter | |
| Engine | |
| Engine | Dongfanghong |
| Power | 130HP |
| Rated speed | 2200r/min |
| Number of cylinders | 4 |
| Transmission | |
| Gearbox | 16F+8R(Optional 24F+8R micro climbing gear |
| Main clutch | Double-acting clutch |
| PTO | Mechanical control |
| Different lock | Machinery |
| PTO shaft speed | 540/1000rpm |
| No of PTO spline | 6 |
| Front hood | |
| New engine hood | Red/Blue |
| Drive system | |
| F/R adjustable steering | / |
| Front axle | / |
| Tyre | 12.4-24/16.9-34 |
| Rim color | Sliver |
| Edge valve protection | / |
| Hydraulic system | |
| Oil joint construction | / |
| Double auxiliary cylinders | / |
| Hydraulic output | 2sets |
| Category | Ⅲ |
| Counterweight | |
| Front | / |
| Rear | / |
| Electrical system | |
| Instrument cluster | / |
| Maintenance-free battery | / |
| LED working lights | / |
| Rotatory warning lights | / |
| Fuel tank | |
| Capacity | 110L+100L |
| Speed | |
| MAX.speed | 40Km/h |
| Dimension | |
| Weight | 4800KG |
| Dimension(L*W*H) | 5050*2250*3050mm |
| Wheel base | 2500mm |
| Wheel track | 1600mm |
| Min.ground clearance | 480mm |
With technological innovation, our product configuration and parameters will continue to
change without notice;
if there is any doubt, the specific confirmation of our international trade sales shall prevail;
Of course. Please let us know the specific product model you are interested in and we will immediately send you the latest technical specifications, test reports and our existing certifications (such as CE, RoHS, FCC, etc.) via email.
Yes, we offer professional OEM and ODM services. We have a strong R&D and engineering team. Please provide us with your detailed requirements or design draft, and we will evaluate the feasibility and provide you with a proposal and quotation.
We accept a variety of secure payment methods, including: · T/T (Telegraphic Transfer): This is our most commonly used method. The down payment ratio is a 30% deposit, and the final payment is 70%, payable before shipment. · L/C (Letter of Credit): We accept letters of credit at sight, but they must be issued by a reputable bank.
Our standard production time is approximately 30 days after receiving the deposit. The specific time may vary slightly depending on the order quantity and production schedule. Once the order is confirmed, we will provide you with a precise production schedule.
