| parameter |
| Engine |
| Engine | Xinchai |
| Power | 45HP-75HP |
| Rated speed | 2400r/min |
| Number of cylinders | 4 |
| Transmission |
| Gearbox | 12F+12R |
| Main clutch | Double-acting clutch |
| PTO | Mechanical control |
| Different lock | Machinery |
| PTO shaft speed | 540/1000rpm |
| No of PTO spline | 6 |
| Front hood |
| New engine hood | Red/Blue |
| Drive system |
| F/R adjustable steering | / |
| Front axle | / |
| Tyre | 8.3-20/12.4-28 |
| Rim color | Sliver |
| Edge valve protection | / |
| Rim color | Mechanical control |
| Service brakes | Mechanical control |
Hydraulic system
/ |
| Oil joint construction | / |
| Double auxiliary cylinders | / |
| Hydraulic output | 2sets |
| Category | Ⅱ |
| Counterweight |
| Front | / |
| Rear | / |
| Electrical system |
| Instrument cluster | / |
| Maintenance-free battery | / |
| LED working lights | / |
| Rotatory warning lights | / |
| Fuel tank |
| Capacity | 60L |
| Speed |
| MAX.speed | 32Km/h |
| Steering |
| Hydraulic steering | / |
Dimension
/ |
| Weight | 2600KG |
| Dimension（L*W*H) | 4190*1790*2690mm |
| Wheel base | 2090 |
| Wheel track | 1200mm，1300mm |
| Min.ground clearance | 370mm |
A 60-horsepower agricultural tractor is a multi-functional agricultural machine designed to improve operational efficiency and widely used in various farmlands and terrains. Its core uses include field operations, transportation, and adaptability to different agricultural scenarios.
Field Operations: These tractors are equipped with a rear-mounted three-point suspension system, allowing for efficient integration with various implements, such as: plows and harrows for land preparation, rotary tillers for soil breaking, seeders for sowing, harvesters for harvesting, cultivators for weeding and loosening soil, and ditchers for planting ditches. Some models, such as the Changfa CFC600, can achieve an efficiency of up to 14 acres/hour during rotary tillage, with fuel consumption as low as 0.68 liters/acre, significantly increasing output per unit time. Models like the Qilu Changli CL600-2 also support operations in complex terrains such as orchards and hills, demonstrating strong adaptability.
Transportation and Multi-Scenario Applications:The 60hp tractor also functions as a road transport vehicle, with a road speed of up to 38 km/h, facilitating relocation and cargo transport. Its power take-off shaft (540/760 rpm) can drive power generation or irrigation equipment, extending its application to fixed operation scenarios and meeting the diverse needs of farms and cooperatives.
Adaptability and Efficiency: Through a multi-speed gearbox (such as 16+16 gears) and hydraulic suspension system, the tractor can flexibly adapt to different agronomic requirements, improving operational accuracy and efficiency. Ground clearance design (such as 356 mm) enhances passability, making it suitable for various environments such as plains, mountains, and pastoral areas.
With technological innovation, our product configuration and parameters will continue to
change without notice;
if there is any doubt, the specific confirmation of our international trade sales shall prevail;
