| parameter |
| Engine |
| Engine | Yunnei |
| Power | 80HP,85HP,90HP |
| Rated speed | 2400r/min |
| Number of cylinders | 4 |
| Transmission |
| Gearbox | 12F+12R |
| Main clutch | Double-acting clutch |
| PTO | Mechanical control |
| Different lock | Machinery |
| PTO shaft speed | 540/1000rpm |
| No of PTO spline | 6 |
| Front hood |
| New engine hood | Red/Blue |
| Drive system |
| F/R adjustable steering | / |
| Front axle | / |
| Tyre | 9.5-24/14.9-30 |
| Rim color | Sliver |
| Edge valve protection | / |
| Rim color | Mechanical control |
| Service brakes | Mechanical control |
Hydraulic system
/ |
| Oil joint construction | / |
| Double auxiliary cylinders | / |
| Hydraulic output | 2sets |
| Category | Ⅱ |
| Counterweight |
| Front | / |
| Rear | / |
| Electrical system |
| Instrument cluster | / |
| Maintenance-free battery | / |
| LED working lights | / |
| Rotatory warning lights | / |
| Fuel tank |
| Capacity | 60L+60L |
| Speed |
| MAX.speed | 32Km/h |
| Steering |
| Hydraulic steering | / |
Dimension
/ |
| Weight | 2750KG |
| Dimension（L*W*H) | 4190*1790*2690mm |
| Wheel base | 2090mm |
| Wheel track | 1200mm，1300mm |
| Min.ground clearance | 370mm |
The 90hp tractor is a medium-sized agricultural machine widely used in various farmland operations. Its front loader further expands its application range, making it valuable in both agricultural and non-agricultural scenarios.
Wide Range of Applications and Adaptability: The 90hp tractor can be equipped with over 40 types of agricultural implements to perform rotary tillage, plowing, sowing, fertilizing, spraying, transportation, potato harvesting, peanut harvesting, and other agronomical operations. It is suitable for complex terrains such as plains, greenhouses, orchards, slopes, and terraced fields. The front loader function enables it to efficiently handle bulk materials, such as loading and unloading fertilizer, straw, sand, or construction waste, replacing manual labor in agricultural storage, landscaping, and small-scale construction projects, thus improving material handling efficiency.
Core Benefits:
High Efficiency and Multifunctionality: The multi-speed gearbox (e.g., 12F+12R) and fully hydraulic steering system provide flexible operation, a small turning radius, reduced blind spots, and increased workload per unit time. The integration of the front loader with the tractor reduces equipment changeover time, achieving integrated tillage and transportation.
Economy and Reliability: High-pressure common rail engines or electronically controlled unit pumps reduce fuel consumption; large fuel tanks (e.g., 150 liters) support long-term continuous operation, reducing downtime; reinforced chassis and independent oil circuit system improve durability and reduce failure rate.
Adaptability and Comfort:Adjustable rear track and a paddy field-specific front axle enhance stability under different soil conditions; side-mounted control panel and suspended clutch optimize operating comfort and reduce driver fatigue.
Cost-Effectiveness:With a reference price of approximately 78,100 yuan and eligibility for agricultural machinery subsidies, initial investment is low; multi-functionality reduces the need for multiple pieces of equipment, lowering labor and operating costs in the long term.
With technological innovation, our product configuration and parameters will continue to
change without notice;
if there is any doubt, the specific confirmation of our international trade sales shall prevail;
