| Parameters |
|
| Power type | Diesel |
| Rated load | 4500KG |
| The external dimensions are length, width and height | 4430*1950*2775mm |
| Load center distance | 500mm |
| The maximum height that the forks can lift | 4270mm |
| Maximum lifting height | 3000mm |
| The full height of the mast (with the forks on the ground and the mast vertical) | 2211mm |
| Freely increase height | 100mm |
| Front overhang | 667mm |
| Rear overhang | 1320mm |
| Wheelbase | 2200mm |
| Minimum ground clearance (at the mast) | 340mm |
| Track length (front wheel/rear wheel) | 1540/1540mm |
| Inside the minimum turning radius | 2632mm |
| Outside the minimum turning radius | 4530mm |
| Mast tilt Angle (front/rear) | F8°,R10° |
| Fork size | 1220*45*120mm |
| Maximum driving speed (full load/empty load) | 30/35Km/h |
| Speed increase (full load/empty load) | 350/500mm/s |
| Speed decrease (full load/empty load) | 550/450mm/s |
| Maximum climbing capacity (full load/empty load) | 25/35° |
| Number of wheels X/ Drive wheels | 4X/4 |
| Tire type (front/rear) | Pneumatic tire |
| Front wheel tire | 16/70-20 |
| Rear wheel tire | 16/70-20 |
| Service brake | Disc brakes |
| Parking brake | Mechanical handbrake |
| Engine model (Foreign trade) | Quanchai National II 490/490 turbocharged engine |
| Engine power (Foreign trade) | 42/55（58）Kw |
| Model of reducer | 265 |
| Total weight | 4730KG |
We are a source factory and can customize according to your needs. Today, we'll share the difference between a four-wheel drive off-road forklift and a regular forklift. An off-road forklift has a high chassis and four-wheel drive (single or double cab). Its high chassis and large tires allow it to handle various complex terrains and are primarily used in the field.
Off-road forklifts also solve the problems of driving on hillsides and muddy roads. They are generally large, have a stable chassis, and good four-wheel drive for excellent off-road capability, mainly used in complex terrains such as airports, ports, subways, mines, or construction sites.
Regular forklifts are generally two-wheel drive, have a low chassis, and are smaller in size, mostly used in workshops, factories, or places with good ground conditions and infrastructure. In general, four-wheel drive off-road forklifts are used for outdoor work, while regular forklifts are mainly used indoors. Off-road forklifts have a stronger ability to adapt to complex terrain, while ordinary forklifts are only suitable for flat ground; Design features: Off-road forklifts have a more robust structure, with representative models including the 5-ton red four-wheel drive, the green 3.5-ton and the green 3.5-ton, and the ordinary forklift is the red 3.5-ton as an example; 3. Product recommendations: If you need a forklift with high off-road performance.
With technological innovation, our product configuration and parameters will continue to
if there is any doubt, the specific confirmation of our international trade sales shall prevail;
