2026 Mini Pay Loader & Small Articulated Wheel Loader Guide

BrandSEMGATY
Product originCHINA
Delivery time30days
Supply capacityAnnual production and supply capacity 2000 units

1.Excellent Heavy-Duty & Lifting Performance Powered by a robust 65kW engine, it delivers an impressive maximum traction force of 100KN and breakout force of 56KN. With a maximum dump height of 3600mm, it excels in loading high-sided trucks and handling demanding heavy-duty tasks. 2.Efficient & Reliable Powertrain Equipped with a National III compliant Yunnei (YN4EL109-30CR) engine, paired with a single-stage four-element twin-turbine torque converter and a planetary power shift transmission. This setup ensures smooth power delivery and great fuel economy, while the 2-forward/2-reverse gear design perfectly balances explosive digging power with travel speed. 3.Durable Chassis & Superior Braking System Built with reinforced drive axles and grade 1 planetary reduction, combined with a responsive 16MPa high-pressure hydraulic system for solid structural integrity. It also comes standard with four-wheel oil-cap disc service brakes and a manual disc parking brake, significantly enhancing operational safety and reliability in complex working conditions.

parameter
Performance	1	Rated loading	2000kg
	2	Overall weight	5200kg
	3	Bucket capacity	1.2m3
	4	Maximum traction force	100KN
	5	Maximum breakout force	56KN
	6	Maximum grade ability	28℃
	7	Maximum dump height	3600mm
	8	Maximum dump reach	900mm
	9	Overall dimension (L×W×H)	625020002850mm
Engine	10	Model	YN4EL109-30CR
	11	Type	lnline / water cooling/ dry cylinder injection
	13	Rated power	65kw-2400r/min
	14	Maximum torque	147N.M
	15	Emission standards	National III
Transmission system	16	Torque converter	Single-stage four-element twin-turbine torque converter
	16	Torque converter	Single-stage four-element twin-turbine torque converter
	17	Gearbox mode	Planetary power transmission
	18	Gears	2forward shift 2reverse shift
	18	Gears	2forward shift 2reverse shift
	19	Maximum speed	25km/h
Drive axles	20	Main reducing spiral	bevel gear grade 1reduction
	21	Decelerating mode	Planetary reduction grade 1
	21	Decelerating mode	Planetary reduction grade 1
	22	Wheel base (mm)	2450mm
	23	Wheel tread	1580mm
Hydraulic system	24	System working pressure	16MPa


	25	Boom lifting time	8.9s
	26	Total time	10±0.2s
Brake system	27	Service brake	Four-wheel brake with oil cap and disc
	27	Service brake	Four-wheel brake with oil cap and disc
	28	Parking brake	Manual disc type
Tyre	29	Type specification	1670-20
	29	Type specification	1670-20
	30	Front tyre pressure	0.4Mpa
	31	Rear tyre pressure	0.35Mpa

🚜 Efficient & Versatile · Agile Heavy Lifter — New Generation 2-Ton Wheel Loader

Specially engineered for small to medium-scale operations, this 2-ton wheel loader stands out with its exceptional power matching and agile maneuverability. It is the ideal choice for municipal construction, farmland water conservancy, warehousing logistics, and confined space operations. Not only does it inherit the rugged durability of traditional loaders, but it also achieves a breakthrough in lifting height and traction force within its class.

💪 Powerful Performance, Heavy-Duty Capability
Powered by a Yunnei (YN4EL109-30CR) inline water-cooled engine that meets National III emission standards, it delivers a rated power of 65kW with ample torque and excellent fuel economy. Paired with a single-stage four-element twin-turbine torque converter and a planetary power shift transmission, the machine boasts extremely high transmission efficiency. With a maximum traction force of up to 100KN and a breakout force of 56KN, it offers explosive power when loading loose materials like gravel and coal, effortlessly handling various heavy-duty challenges.

🏗️ Superior Lifting Height, Effortless Loading
As a 2-ton class machine, it offers an impressively versatile working range. The maximum dump height reaches 3600mm, combined with a 900mm dump reach, perfectly accommodating the loading and unloading needs of high-sided trucks and various transport vehicles. This effectively solves the common "not reaching high enough" pain point found in many small loaders. Its 1.2m³ standard bucket capacity and 5200kg overall weight ensure both operational stability and high efficiency.

🛡️ Agile Chassis, Safe & Stable

With overall dimensions of 6250×2000×2850mm and a 2450mm wheelbase, the machine features a compact turning radius. It can easily maneuver in tight spaces with extreme steering flexibility. The chassis utilizes reinforced drive axles and grade 1 planetary reduction for a solid and durable structure. The braking system comes standard with four-wheel oil-cap disc service brakes and a manual disc parking brake, providing solid and reliable safety assurance whether operating on slopes or during daily travel.
