| parameter |
| Performance | 1 | Rated loading | 2500KG |
| 2 | Overall weight | 6400KG |
| 3 | Bucket capacity | 1.5m3 |
| 4 | Maximum traction force | 100Kn |
| 5 | Maximum breakout force | 65Kn |
| 6 | Maximum grade ability | 28℃ |
| 7 | Maximum dump height | 3600mm |
| 8 | Maximum dump reach | 900mm |
| 9 | Overall dimension (L×W×H) | 6500*2200*2950mm |
| Engine | 10 | Model | YN48GBZ(4108) |
| 11 | Type | lnline/ Water cooling/ Dry cylinder/ Injection |
| 13 | Rated power | 92kw-2400r/min |
| 14 | Maximum torque | 147N.M |
| 15 | Emission standards | National II |
| Transmission system | 16 | Torque converter | Single-stage four-element twin-turbine torque converter |
| 17 | Gearbox mode | Fixed-axis power transmission (300) |
| 18 | Gears | 2forward shift 2reverse shift |
|
| 19 | Maximum speed | 28Km/h |
| Drive axles | 20 | Main reducing spiral | Bevel gear grade 1reduction |
| 21 | Decelerating mode | Planetary reduction grade 1 |
|
| 22 | Wheel base (mm) | 2650mm |
| 23 | Wheel tread | 1700mm |
| Hydraulic system | 24 | System working pressure | 16MPa |
| 25 | Boom lifting time | 8.9s |
| 26 | Total time | 10±0.2s |
| Brake system | 27 | Service brake | Four-wheel brake with oil cap and disc |
|
| 28 | Parking brake | Manual disc type |
| Tyre | 29 | Type specification | 1670-24 |
| 30 | Front tyre pressure | 0.4Mpa |
| 31 | Rear tyre pressure | 0.35Mpa |
The 2.5-ton small articulated wheel loader is a compact construction machine suitable for site leveling, earthmoving, landscaping, and other similar applications. It features high mobility and a small turning radius. The following information is based on relevant data.
Main Features and Configurations:
This type of loader typically uses an articulated frame design to enhance operational flexibility. The power system is mostly equipped with a diesel engine; for example, some models feature a Yunnei engine with a power output of approximately 37KW or similar specifications, meeting China III or higher emission standards. The hydraulic system uses internationally renowned pumps and valves to ensure operational efficiency; the cab prioritizes operator comfort and may integrate features such as an adjustable seat and anti-glare glass.
The Small Articulating Compact Wheel Loader is suitable for space-constrained working environments, such as agriculture, municipal engineering, or indoor construction.
Advantages include:
Economy: The energy-saving design of the hydraulic system reduces fuel consumption, and some electric models offer significant operating cost savings.
Reliability:
Dustproof seals and cold-pressed steel tubing enhance durability; optional ROPS/FOPS cabs improve safety.
Versatility:
Optional attachments such as side-dump buckets and clean-up devices are available to adapt to various tasks, including excavation and loading.
Pricing and Purchase Recommendations:
Prices are significantly affected by brand and configuration. For example, imported brands may be more expensive than domestic brands for the same tonnage. When purchasing, consider the workload, maintenance costs, and after-sales service.For specific model comparisons or the latest quotes, it is recommended to consult a professional supplier for detailed specifications.
With technological innovation, our product configuration and parameters will continue to change without notice;
if there is any doubt, the specific confirmation of our international trade sales shall prevail;
