| parameter | |
| Power type | Electric |
| Rated load | 1500KG |
| The external dimensions are length, width and height | 2230*1170*2170mm |
| Load center distance | 500mm |
| The forklift lands at the static height, and the mast reaches its full height | 2090mm |
| Maximum lifting height | 3000mm |
| The distance from the front overhang to the center of the front axle and the center end of the arrival fork | 430mm |
| The distance from the center point of the rear axle to the very end of the rear overhang | 420mm |
| The vertical distance from the center of the front axle to the center of the rear axle is the wheelbase | 1480mm |
| Minimum ground clearance (at the mast) | 100mm |
| Track length (front wheel/rear wheel) | 960/930mm |
| Inside the minimum turning radius | 1200mm |
| Outside the minimum turning radius | 1480mm |
| Mast tilt Angle (front/rear) | F6, R12 |
| Fork size | 1070*45*120mm |
| Maximum driving speed (full load/empty load) | 13/16km/h |
| Maximum climbing capacity (full load/empty load) | 12/14° |
| Number of wheels X/ Drive wheels | 4X/2 |
| Tire type (front/rear) | Custom solid tires |
| Front wheel tire | 6.50-10 |
| Rear wheel tire | 5.00-8 |
| Lighting and signals | Headlights, left and right turn signals, brake lights, daytime running lights, instrument panel, electric horn, etc. |
| Steering mode | Hydraulic power assist |
| Controller | Jiaheng |
| Battery (Voltage/Capacity) | 60V 70Ah |
| Battery | 5 maintenance-free batteries(12V-70Ah) |
| Walking motor | 3/60Kw/V |
| Oil pump motor | 4/48-72Kw/V |
| Total weight | 2510KG |
With technological innovation, our product configuration and parameters will continue to
change without notice;
if there is any doubt, the specific confirmation of our international trade sales shall prevail;
